Time for another entry in the EXPLAIN FORMAT=JSON is cool! series. Today we’re going to look at how you can view the buffer result using JSON (instead of the regular
EXPLAIN command.
Regular EXPLAIN does not identify if SQL_BUFFER_RESULT was used at all. To demonstrate, let’s run this query:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
mysql> explain select * from salariesG *************************** 1. row *************************** id: 1 select_type: SIMPLE table: salaries partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 2557022 filtered: 100.00 Extra: NULL 1 row in set, 1 warning (0.01 sec) Note (Code 1003): /* select#1 */ select `employees`.`salaries`.`emp_no` AS `emp_no`,`employees`.`salaries`.`salary` AS `salary`,`employees`.`salaries`.`from_date` AS `from_date`,`employees`.`salaries`.`to_date` AS `to_date` from `employees`.`salaries` |
Now, let’s compare it to this query:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
mysql> explain select sql_buffer_result * from salariesG *************************** 1. row *************************** id: 1 select_type: SIMPLE table: salaries partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 2557022 filtered: 100.00 Extra: Using temporary 1 row in set, 1 warning (0.00 sec) Note (Code 1003): /* select#1 */ select sql_buffer_result `employees`.`salaries`.`emp_no` AS `emp_no`,`employees`.`salaries`.`salary` AS `salary`,`employees`.`salaries`.`from_date` AS `from_date`,`employees`.`salaries`.`to_date` AS `to_date` from `employees`.`salaries` |
Notice there is no difference, except the expected "Using temporary" value in the "Extra" row of the second query. The field "Using temporary" is expected here, because SQL_BUFFER_RESULT directly instructs the MySQL server to put a result set into a temporary table to free locks. But what if the query uses the temporary table by itself? For example, for a grouping operation? In this case, the EXPLAIN result for the original query and the query that contains the SQL_BUFFER_RESULT clause will be 100% identical.
Compare:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
mysql> explain select emp_no, salary/avg(salary) from salaries group by emp_no, salaryG *************************** 1. row *************************** id: 1 select_type: SIMPLE table: salaries partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 2557022 filtered: 100.00 Extra: Using temporary; Using filesort 1 row in set, 1 warning (0.00 sec) Note (Code 1003): /* select#1 */ select `employees`.`salaries`.`emp_no` AS `emp_no`,(`employees`.`salaries`.`salary` / avg(`employees`.`salaries`.`salary`)) AS `salary/avg(salary)` from `employees`.`salaries` group by `employees`.`salaries`.`emp_no`,`employees`.`salaries`.`salary` |
With:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
mysql> explain select sql_buffer_result emp_no, salary/avg(salary) from salaries group by emp_no, salaryG *************************** 1. row *************************** id: 1 select_type: SIMPLE table: salaries partitions: NULL type: ALL possible_keys: NULL key: NULL key_len: NULL ref: NULL rows: 2557022 filtered: 100.00 Extra: Using temporary; Using filesort 1 row in set, 1 warning (0.00 sec) Note (Code 1003): /* select#1 */ select sql_buffer_result `employees`.`salaries`.`emp_no` AS `emp_no`,(`employees`.`salaries`.`salary` / avg(`employees`.`salaries`.`salary`)) AS `salary/avg(salary)` from `employees`.`salaries` group by `employees`.`salaries`.`emp_no`,`employees`.`salaries`.`salary` |
There is no difference! We not able to tell if we used a temporary table to resolve the query, or simply put the result set into the buffer. The EXPLAIN FORMAT=JSON command can help in this case as well. Its output is clear, and shows all the details of the query optimization:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 |
mysql> explain format=json select sql_buffer_result emp_no, salary/avg(salary) from salaries group by emp_no, salaryG *************************** 1. row *************************** EXPLAIN: { "query_block": { "select_id": 1, "cost_info": { "query_cost": "3073970.40" }, "grouping_operation": { "using_temporary_table": true, "using_filesort": true, "cost_info": { "sort_cost": "2557022.00" }, "buffer_result": { "using_temporary_table": true, "table": { "table_name": "salaries", "access_type": "ALL", "rows_examined_per_scan": 2557022, "rows_produced_per_join": 2557022, "filtered": "100.00", "cost_info": { "read_cost": "5544.00", "eval_cost": "511404.40", "prefix_cost": "516948.40", "data_read_per_join": "39M" }, "used_columns": [ "emp_no", "salary", "from_date" ] } } } } } 1 row in set, 1 warning (0.00 sec) Note (Code 1003): /* select#1 */ select sql_buffer_result `employees`.`salaries`.`emp_no` AS `emp_no`,(`employees`.`salaries`.`salary` / avg(`employees`.`salaries`.`salary`)) AS `salary/avg(salary)` from `employees`.`salaries` group by `employees`.`salaries`.`emp_no`,`employees`.`salaries`.`salary` |
Firstly, we can see how the grouping_operation was optimized:
"grouping_operation": { "using_temporary_table": true, "using_filesort": true,
And it does indeed use the temporary table.
Now we can follow the details for SQL_BUFFER_RESULT:
|
1 2 |
"buffer_result": { "using_temporary_table": true, |
With this output, we can be absolutely certain that the temporary table was created for both the SQL_BUFFER_RESULT and the grouping operation. This is especially helpful for support engineers who need the EXPLAIN output to help their customers to tune queries, but are afraid to ask for the same query twice — once with the SQL_BUFFER_RESULT clause and once without.
Conclusion: EXPLAIN FORMAT=JSON does not hide important details for query optimizations.
