How Percona XtraDB Cluster certification works

April 17, 2016

Author

Krunal Bauskar

Percona Software

Share this Post:

In this blog, we’ll discuss how Percona XtraDB Cluster certification works. Percona XtraDB Cluster replicates actions executed on one node to all other nodes in the cluster and make it fast enough to appear as it if is synchronous (aka virtually synchronous).

Let’s understand all the things involved in the process (without losing data integrity).

There are two main types of actions: DDL and DML. DDL actions are executed using Total Order Isolation (let’s ignore Rolling Schema Upgrade for now) and DML using normal Galera replication protocol. This blog assumes the reader is aware of Total Order Isolation and MySQL replication protocol.

- DML (Insert/Update/Delete) operations effectively change the state of the database, and all such operations are recorded in XtraDB by registering a unique object identifier (aka key) for each change (an update or a new addition). Let’s understand this key concept in a bit more detail.
  - - A transaction can change “n” different data objects. Each such object change is recorded in XtraDB using a so-call append_key operation. The append_key operation registers the key of the data object that has undergone a change by the transaction. The key for rows can be represented in three parts as db_name, table_name, and pk_columns_for_table (if pk is absent, a hash of the complete row is calculated). In short there is quick and short meta information that this transaction has touched/modified following rows. This information is passed on as part of the write-set for certification to all the nodes of a cluster while the transaction is in the commit phase.
  - - For a transaction to commit it has to pass XtraDB-Galera certification, ensuring that transactions don’t conflict with any other changes posted on the cluster group/channel. Certification will add the keys modified by given the transaction to its own central certification vector (CCV), represented by cert_index_ng. If the said key is already part of the vector, then conflict resolution checks are triggered.
  - - Conflict resolution traces reference the transaction (that last modified this item in cluster group). If this reference transaction is from some other node, that suggests the same data was modified by the other node and changes of that node have been certified by the local node that is executing the check. In such cases, the transaction that arrived later fails to certify.

- Changes made to DB objects are bin-logged. This is the same as how MySQL does it for replication with its Master-Slave eco-system, except that a packet of changes from a given transaction is created and named as a write-set.

Once the client/user issues a “COMMIT”, XtraDB Cluster will run a commit hook. Commit hooks ensure following:

- Flush the binlogs.

- Check if the transaction needs replication (not needed for read-only transactions like SELECT).

- If a transaction needs a replication, then it invokes a pre_commit hook in the Galera eco-system. During this pre-commit hook, a write-set is written in the group channel by a “replicate” operation. All nodes (including the one that executed the transaction) subscribes to this group-channel and reads the write-set.

- gcs_recv_thread is first to receive the packet, which is then processed through different action handlers.

Each packet read from the group-channel is assigned an “id”, which is a locally maintained counter by each node in sync with the group. When any new node joins the group/cluster, a seed-id for it is initialized to the current active id from group/cluster. (There is an inherent assumption/protocol enforcement that all nodes read the packet from a channel in same order, and that way even though each packet doesn’t carry “id” information it is inherently established using the local maintained “id” value).

/* Common situation -
* increment and assign act_id only for totally ordered actions
* and only in PRIM (skip messages while in state exchange) */
rcvd->id = ++group->act_id_;

[This is an amazing way to solve the problem of the id co-ordination in multiple master
system, otherwise a node will have to first get an id from central system or
through a separate agreed protocol and then use it for the packet there-by
doubling the round-trip time].

1

2

3

4

5

6

7

8

9

/* Common situation -

* increment and assign act_id only for totally ordered actions

* and only in PRIM (skip messages while in state exchange) */

rcvd->id = ++group->act_id_;

[This is an amazing way to solve the problem of the id co-ordination in multiple master

system, otherwise a node will have to first get an id from central system or

through a separate agreed protocol and then use it for the packet there-by

doubling the round-trip time].

- What happens if two nodes get ready with their packet at same time?
  - - Both nodes will be allowed to put the packet on the channel. That means the channel will see packets from different nodes queued one-behind-another.
  - - It is interesting to understand what happens if two nodes modify same set of rows. Let’s take an example:

     create -> insert (1,2,3,4)....nodes are in sync till this point.
     node-1: update i = i + 10;
     node-2: update i = i + 100;

Let's associate transaction-id (trx-id) for an update transaction that is executed on
node-1 and node-2 in parallel (The real algorithm is bit more involved (with uuid + seqno) but
conceptually the same so for ease I am using trx_id)

node-1:
   update action: trx-id=n1x
node-2:
   update action: trx-id=n2x

Both node packets are added to the channel but the transactions are conflicting. Let's see which
one succeeds. The protocol says: FIRST WRITE WINS. So in this case, whoever is first to write
to the channel will get certified. Let's say node-2 is first to write the packet
and then node-1 makes immediately after it.

NOTE: each node subscribes to all packages including its own package.
See below for details.

Node-2:
- Will see its own packet and will process it.
- Then it will see node-1 packet that it tries to certify but fails. (Will talk about
certification protocol in little while)

Node-1:
- Will see node-2 packet and will process it. (Note: InnoDB allows isolation and so node-1
can process node-2 packets independent of node-1 transaction changes)
- Then it will see the node-1 packet that it tries to certify but fails. (Note even though the
packet originated from node-1 it will under-go certification to catch cases like thes. This
is beauty of listening to own events that make consistent processing path even if
events are locally generated)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

create -> insert (1,2,3,4)....nodes are in sync till this point.

node-1: update i = i + 10;

node-2: update i = i + 100;

Let's associate transaction-id (trx-id) for an update transaction that is executed on

node-1 and node-2 in parallel (The real algorithm is bit more involved (with uuid + seqno) but

conceptually the same so for ease I am using trx_id)

node-1:

update action: trx-id=n1x

node-2:

update action: trx-id=n2x

Both node packets are added to the channel but the transactions are conflicting. Let's see which

one succeeds. The protocol says: FIRST WRITE WINS. So in this case, whoever is first to write

to the channel will get certified. Let's say node-2 is first to write the packet

and then node-1 makes immediately after it.

NOTE: each node subscribes to all packages including its own package.

See below for details.

Node-2:

- Will see its own packet and will process it.

- Then it will see node-1 packet that it tries to certify but fails. (Will talk about

certification protocol in little while)

Node-1:

- Will see node-2 packet and will process it. (Note: InnoDB allows isolation and so node-1

can process node-2 packets independent of node-1 transaction changes)

- Then it will see the node-1 packet that it tries to certify but fails. (Note even though the

packet originated from node-1 it will under-go certification to catch cases like thes. This

is beauty of listening to own events that make consistent processing path even if

events are locally generated)

- Now let’s talk about the certification protocol using the example sighted above. As discussed above, the central certification vector (CCV) is updated to reflect reference transaction.

Node-2:
- node-2 sees its own packet for certification, adds it to its local CCV and performs
certification checks. Once these checks pass it updates the reference transaction by
setting it to "n2x"

- node-2 then gets node-1 packet for certification. Said key is already present in
CCV with a reference transaction set it to "n2x", whereas write-set proposes setting it to
"n1x". This causes a conflict, which in turn causes the node-1 originated transaction to
fail the certification test.

This helps point out a certification failure and the node-1 packet is rejected.

Node-1:
- node-1 sees node-2 packet for certification, which is then processed, the
local CCV is updated and the reference transaction is set to "n2x"
- Using the same case explained above, node-1 certification also rejects the node-1 packet.

Well this suggests that the node doesn't need to wait for certification to complete, but
just needs to ensure that the packet is written to the channel. The applier transaction will always
win and the local conflicting transaction will be rolled back.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

Node-2:

- node-2 sees its own packet for certification, adds it to its local CCV and performs

certification checks. Once these checks pass it updates the reference transaction by

setting it to "n2x"

- node-2 then gets node-1 packet for certification. Said key is already present in

CCV with a reference transaction set it to "n2x", whereas write-set proposes setting it to

"n1x". This causes a conflict, which in turn causes the node-1 originated transaction to

fail the certification test.

This helps point out a certification failure and the node-1 packet is rejected.

Node-1:

- node-1 sees node-2 packet for certification, which is then processed, the

local CCV is updated and the reference transaction is set to "n2x"

- Using the same case explained above, node-1 certification also rejects the node-1 packet.

Well this suggests that the node doesn't need to wait for certification to complete, but

just needs to ensure that the packet is written to the channel. The applier transaction will always

win and the local conflicting transaction will be rolled back.

- What happens if one of the nodes has local changes that are not synced with group.

create (id primary key) -> insert (1), (2), (3), (4);
node-1: wsrep_on=0; insert (5); wsrep_on=1
node-2: insert(5).
insert(5) will generate a write-set that will then be replicated to node-1.
node-1 will try to apply it but will fail with duplicate-key-error, as 5 already exist.
XtraDB will flag this as an error, which would eventually cause node-1 to shutdown.

1

2

3

4

5

6

create (id primary key) -> insert (1), (2), (3), (4);

node-1: wsrep_on=0; insert (5); wsrep_on=1

node-2: insert(5).

insert(5) will generate a write-set that will then be replicated to node-1.

node-1 will try to apply it but will fail with duplicate-key-error, as 5 already exist.

XtraDB will flag this as an error, which would eventually cause node-1 to shutdown.

- With all that in place, how is GTID incremented if all the packets are processed by all nodes (including ones that are rejected due to certification)? GTID is incremented only when the transaction passes certification and is ready for commit. That way errant-packets don’t cause GTID to increment. Also, don’t confuse the group packet “id” quoted above with GTID. Without errant-packets, you may end up seeing these two counters going hand-in-hand, but they are no way related.
