Simulating InnoDB Secondary Index Corruption

InnoDB Secondary Index CorruptionWorking as a support engineer here at Percona is amazing, as you get a variety of requests, ranging from the most trivial questions to questions that require source code review and understanding of the internals of InnoDB, for example.

In our world where High Availability is a must, everything is about being pro-active, and when we need to be reactive we must act fast. To do so we need to ensure we have proper monitoring in place that covers all possible failure scenarios. Unfortunately, that is not always possible and we are always improving and learning as we face new types of issues.

A few days ago one of our customers faced an issue where MySQL identified an InnoDB secondary index corruption and marked that table as corrupted instead of crashing the server. Even though one would think that a single table marked as corrupted is not as bad as an entire server crash, this particular table was key for the whole application, which in the end caused an outage anyway. They wanted to artificially simulate this situation in order to improve their QA / Monitoring.

The Error

InnoDB will retry the read 100 times, and if it fails on all of the attempts, the server will assert – otherwise the behavior will vary depending on the version you are using. On 5.5 it will consider the table as corrupted while on 5.7 it will mark the table missing on the data dictionary. Either way, from this moment forward, all queries on that particular table will fail.

InnoDB Internals

InnoDB has a defined layout for it’s in disk structures (redo log, .ibd files, …).

If you are interested in learning or poking around, Jeremy Cole has a project to diagram most of the internal InnoDB structures at https://github.com/jeremycole/innodb_diagrams and also a powerful tool to extract data from innodb at https://github.com/jeremycole/innodb_ruby. The intention of this post is to show you how you can do it manually, so you can get more exposure to internals.

To simulate the corruption we will need to read only a small part of each page header. Here is the list and it’s location as per 5.7 source code:

  • Each page is defined by a type – FIL_PAGE_TYPE
  • An index page has a value of 45bf (or 17855 in decimal) – FIL_PAGE_INDEX
  • Checksum is stored from byte/offset 0 to 4 of each page – FIL_PAGE_SPACE_OR_CHKSUM
  • Index ID is stored at byte/offset 28 of each page data – PAGE_INDEX_ID

Source code:
storage/innobase/include/fil0fil.h#L507
storage/innobase/include/fil0fil.h#L575
storage/innobase/include/fil0fil.h#L483
storage/innobase/include/btr0btr.ic#L109
storage/innobase/include/page0page.h#L56
storage/innobase/include/fsp0types.h#L68
storage/innobase/include/fil0fil.h#L560
storage/innobase/include/page0page.h#L82

To extract the above information from an .ibd file I will use a small bash script to read each page from the file and export the information we will need:

The last piece for the puzzle is to translate the Index ID to our secondary index. To do it we will make usage of the information_schema table:

Reproducible test case

To reproduce the corruption we will use a test table with one primary key, one secondary index, and 1000 rows:

At this point, InnoDB has all the table pages already loaded into InnoDB Buffer Pool. We will force it to read the pages from disk. The most efficient way will be by adding innodb_buffer_pool_load_at_startup=OFF to my.cnf and restart MySQL.

We would now like to check the list of  Index ID’s of test/tb1 table:

We will be looking for pages which have a type 45bf (FIL_PAGE_INDEX) and Index ID 31. It’s time to execute our bash script to read the .ibd file:

Let’s get page eight as the page we will be manipulating. It starts at offset 131072 of tb1.ibd, has a page type 45bf, the index ID field is 31, and it has a checksum of dc67f354. To manipulate the page, we will be changing the checksum field to dc67f355.

Now, next time we try to read this particular page, MySQL will identify a corruption because the checksum doesn’t match. We don’t want the server to assert, so we will change the checksum back to its original value right after we attempt to read the table. This way MySQL will only mark this table as corrupted and as missing in the data dictionary:

That is it! We have provoked an InnoDB secondary index corruption and now all subsequent queries will fail. Now you can make sure your monitoring tool / QA process covers this type of situations.

If in your version of MySQL it has only marked the table as corrupted, a simple CHECK TABLE will bring it back to a usable state. If your version of MySQL is reporting the table as missing from the data dictionary, you can just restart MySQL to force it to re-read the table pages again, since we have changed the checksum back to its original value, it won’t report any error at this time.

Never try to change any MySQL file manually on a production environment. This can cause unrecoverable corruption and data loss.
