Using AWS EC2 instance store vs EBS for MySQL: how to increase performance and decrease cost

 | August 20, 2018 |  Posted In: AWS, Cloud and MySQL, Insight for DBAs, MySQL, Solutions Engineering

PREVIOUS POST
NEXT POST

AWS EC2 MySQL cost savingsIf you are using large EBS GP2 volumes for MySQL (i.e. 10TB+) on AWS EC2, you can increase performance and save a significant amount of money by moving to local SSD (NVMe) instance storage. Interested? Then read on for a more detailed examination of how to achieve cost-benefits and increase performance from this implementation.

EBS vs Local instance store

We have heard from customers that large EBS GP2 volumes can be affected by short term outages—IO “stalls” where no IO is going in or out for a couple of minutes. Statistically, with so many disks in disk arrays (which back EBS volumes) we can expect frequent disk failures. If we allocate a very large EBS GP2 volume, i.e. 10Tb+, hitting such failure events can be common.

In the case of MySQL/InnoDB, such an IO “stall” will be obvious, particularly with the highly loaded system where MySQL needs to do physical IO. During the stall, you will see all write queries are waiting, or “hang”.  Some of the writes may error out with “Error 1030” (MySQL error code 1030 (ER_GET_ERRNO): Got error %d from storage engine). There is nothing MySQL can do here – if the IO subsystem is not available, it will need to wait for it.

The good news is: many of the newer EC2 instances (i.e. i3, m5d, etc) have local SSD disks attached (NVMe). Those disks are local to the physical server and should not suffer from the EBS issues described above. Using local disks can be a very good solution:

  1. They are faster, as they are local to the server, and do not suffer from the EBS issues
  2. They are much cheaper compared to large EBS volumes.

Please note, however, that local storage does not guarantee persistence. More about this below.

Another potential option will be to use IO1 volumes with provisional IOPS. However, it will be significantly more expensive for the large volumes and high traffic.

A look at costs

To estimate the costs, I’ve used the AWS simple monthly calculator. Estimated costs are based on 1 year reserved instances. Let’s imagine we will need to use 14TB volume (to store ~10Tb of MySQL data including binary logs). The pricing estimates will look like this:

r4.4xlarge, 122GB RAM, 16 vCPUs + EBS, 14TB volume (this is what we are presumably using now)

Local storage price estimate:
i3.4xlarge, 122GB RAM, 16 vCPUs, 3800 GiB disk (2 x 1900 NVMe SSD)

i3.8xlarge, 244GB RAM, 32 vCPUs, 7600 GiB disk (4 x 1900 NVMe SSD)

As we can see, even if we switch to i3.8xlarge and get 2x more RAM and 2x more virtual CPUs, faster storage, 10 gigabit network we can still pay 1.5x less per box what we are presumably paying now. Include replication, then that’s paying 1.5x less per each of the replication servers.

But wait … there is a catch.

How to migrate to local storage from EBS

Well, we have some challenges here to migrate from EBS to local instance NVMe storage.

  1. Wait, we are storing ~10Tb and i3.8xlarge have 7600 GiB disk. The answer is simple: compression (see below)
  2. Wait, but the local storage is ephemeral, if we loose the box we will loose our data – that is unacceptable.  The answer is also simple: replication (see below)
  3. Wait, but we use EBS snapshots for backups. That answer is simple too: we can still use EBS (and use snapshots) on 1 of the replication slave (see below)

Compression

To fit i3.8xlarge we only need 2x compression. This can be done with InnoDB row compression (row_format=compressed) or InnoDB page compression, which requires sparse file and hole punching support. However, InnoDB compression may be slower and will only compress ibd files—it does not compress binary logs, frm files, etc.

ZFS

Another option: use the ZFS filesystem. ZFS will compress all files, including binary logs and frm. That can be very helpful if we use a “schema per customer” or “table per customer” approach and need to store 100K – 200K tables in a single MySQL instance. If the data is compressible, or new tables were provisioned without much data in those, ZFS can give a significant disk savings.

I’ve used ZFS (followed Yves blog post, Hands-On Look at ZFS with MySQL). Here are the results of data compression with ZFS (this is real data, not a generated data):

Compression ratio:

As we can see, the original 8.6Tb of data was compressed to 3.2Tb, the compression ratio for MySQL tables is 2.42x, for binary logs 3.75x. That will definitely fit i3.8xlarge.

(For another test, I’ve generated 40 million tables spread across multiple schemas (databases). I’ve added some data only to one schema, leaving others blank. For that test I achieved ~10x compression ratio.)

Conclusion: ZFS can provide you with very good compression ratio, will allow you to use different EC2 instances on AWS, and save you a substantial amount of money. Although compression is not free performance-wise, and ZFS can be slower for some workloads, using local NVMe storage can compensate.

You can find some performance testing for ZFS on linux in this blog post: About ZFS Performance. Some benchmarks comparing EBS and local NVMe SSD storage (i3 instances) can be found in this blog post: Percona XtraDB Cluster on Amazon GP2 Volumes

MyRocks

Another option for compression would be using the MyRocks storage engine in Percona Server for MySQL, which provides compression.

Replication and using local volumes

As the local instance storage is ephemeral we need redundancy: we can use MySQL replication or Percona XtraDB cluster (PXC). In addition, we can use one replication slave—or we can attach a replication slave to PXC—and have it use EBS storage.

Local storage is not durable. If you stop the instance and then start it again, the local storage will probably disappear. (Though reboot is an exception, you can reboot the instance and the local storage will be fine.) In addition if the local storage disappears we will have to recreate MySQL local storage partition (for ZFS, i.e. zpool create or for EXT4/XFS, i.e. mkfs)

For example, using MySQL replication:

MySQL Master AZ 1a, Local storage

Then we can use slave2 for ebs snapshots (if needed). This slave will be more expensive (as it is using EBS) but it can also be used to either serve production traffic (i.e. we can place smaller amount of traffic) or for other purposes (for example analytical queries, etc).

For Percona XtraDB cluster (PXC) we can just use 3 nodes, 1 in each AZ. PXC uses auto-provisioning with SST if the new node comes back blank. For MySQL replication we need some additional things:

  1. Failover from master to a slave if the master will go down. This can be done with MHA or Orchestrator
  2. Ability to clone slave. This can be done with Xtrabackup or ZFS snapshots (if using ZFS)
  3. Ability to setup a new MySQL local storage partition (for ZFS, i.e. zpool create or for EXT4/XFS, i.e. mkfs)

Other options

Here are some totally different options we could consider:

  1. Use IO1 volumes (as discussed). That can be way more expensive.
  2. Use local storage and MyRocks storage engine. However, switching to another storage engine is another bigger project and requires lots of testing
  3. Switch to AWS Aurora. That can be even more expensive for this particular case; and switching to aurora can be another big project by itself.

Conclusions

  1. Using EC2 i3 instances with local NVMe storage can increase performance and save money. There are some limitations: local storage is ephemeral and will disappear if the node has stopped. Reboot is fine.
  2. ZFS filesystem with compression enabled can decrease the storage requirements so that a MySQL instance will fit into local storage. Another option for compression could be to use InnoDB compression (row_format=compressed).

That may not work for everyone as it requires additional changes to the existing server provisioning: failover from master to a slave, ability to clone replication slaves (or use PXC), ability to setup a new MySQL local storage partition, using compression.
