In the very early days of Percona, Vadim wrote very nice post about MySQL GROUP_CONCAT (GROUP_CONCAT).

But I want to show you a bit more about it.

When is MySQL GROUP_CONCAT useful? Usually while working with Support customers I recommend it when you have aggregation of many-to-many info. It makes the view simpler and more beautiful and it doesn’t need much effort to make it work.

The following are some simple examples.

This is a test table:

CREATE TABLE `group_c` (<br>`parent_id` int(11) DEFAULT NULL,<br>`child_id` int(11) DEFAULT NULL<br>) ENGINE=InnoDB;<br><br><code>INSERT INTO group_c(parent_id, child_id)<br>VALUES (1,1),(1,2),(1,3),(2,1),(2,4),(1,4),(2,6),(3,1),(3,2),(4,1),(4,1),(1,1),(5,0);<br>

1	CREATE TABLE `group_c` (<br>`parent_id` int(11) DEFAULT NULL,<br>`child_id` int(11) DEFAULT NULL<br>) ENGINE=InnoDB;<br><br><code>INSERT INTO group_c(parent_id, child_id)<br>VALUES (1,1),(1,2),(1,3),(2,1),(2,4),(1,4),(2,6),(3,1),(3,2),(4,1),(4,1),(1,1),(5,0);<br>

Without grouping info the only way you can check things is:

mysql&gt; SELECT DISTINCT <br>    -&gt; parent_id, child_id<br>    -&gt; FROM group_c<br>    -&gt; ORDER BY parent_id;<br>+-----------+----------+<br>| parent_id | child_id |<br>+-----------+----------+<br>|         1 |        1 |<br>|         1 |        2 |<br>|         1 |        3 |<br>|         1 |        4 |<br>|         2 |        1 |<br>|         2 |        3 |<br>|         2 |        4 |<br>|         2 |        6 |<br>|         3 |        1 |<br>|         3 |        2 |<br>|         4 |        1 |<br>|         5 |        0 |<br>+-----------+----------+<br>12 rows in set (0.00 sec)

mysql> SELECT DISTINCT -> parent_id, child_id -> FROM group_c -> ORDER BY parent_id; +-----------+----------+ | parent_id | child_id | +-----------+----------+ | 1 | 1 | | 1 | 2 | | 1 | 3 | | 1 | 4 | | 2 | 1 | | 2 | 3 | | 2 | 4 | | 2 | 6 | | 3 | 1 | | 3 | 2 | | 4 | 1 | | 5 | 0 | +-----------+----------+ 12 rows in set (0.00 sec)

But it looks much better and easier to read with GROUP_CONCAT:

mysql&gt; SELECT DISTINCT <br>    -&gt; parent_id, GROUP_CONCAT(DISTINCT child_id ORDER BY child_id) AS child_id_list<br>    -&gt; FROM group_c<br>    -&gt; group by parent_id<br>    -&gt; ORDER BY parent_id;<br>+-----------+---------------+<br>| parent_id | child_id_list |<br>+-----------+---------------+<br>|         1 | 1,2,3,4       |<br>|         2 | 1,3,4,6       |<br>|         3 | 1,2           |<br>|         4 | 1             |<br>|         5 | 0             |<br>+-----------+---------------+<br>5 rows in set (0.00 sec)

mysql> SELECT DISTINCT -> parent_id, GROUP_CONCAT(DISTINCT child_id ORDER BY child_id) AS child_id_list -> FROM group_c -> group by parent_id -> ORDER BY parent_id; +-----------+---------------+ | parent_id | child_id_list | +-----------+---------------+ | 1 | 1,2,3,4 | | 2 | 1,3,4,6 | | 3 | 1,2 | | 4 | 1 | | 5 | 0 | +-----------+---------------+ 5 rows in set (0.00 sec)

Easy? Let’s go to production usage and some “real” examples 🙂

Assume you have 4 Support Engineers who were working with 6 Customers this week on 15 issues.

As it usually happens: everyone (sure, except those who are on vacation :)) worked on everything with everybody.

How you would represent it?

Here is my way:

Create test tables:

engineers (id, name, surname, URL) – list of engineers

customers (id, company name, URL) – list of customers

issues (id, customer_id, description) – list of issues assigned to customers

workflow (id, engineer_id, issue_id) – list of actions: issues and engineers who worked on them

-- Engineers<br>CREATE TABLE engineers (<br>id SMALLINT UNSIGNED NOT NULL AUTO_INCREMENT,<br>e_name VARCHAR(30) NOT NULL, <br>e_surname VARCHAR(30) NOT NULL, <br>url VARCHAR(255) NOT NULL, <br>PRIMARY KEY (id)<br>) ENGINE=InnoDB;<br><br>-- Customers<br>CREATE TABLE customers (<br>id SMALLINT UNSIGNED NOT NULL AUTO_INCREMENT,<br>company_name VARCHAR(30) NOT NULL, <br>url VARCHAR(255) NOT NULL, <br>PRIMARY KEY (id)<br>) ENGINE=InnoDB;<br><br>-- Issues (Issue-Customer)<br>CREATE TABLE issues (<br>id MEDIUMINT UNSIGNED NOT NULL AUTO_INCREMENT,<br>customer_id VARCHAR(30) NOT NULL, <br>description TEXT, <br>PRIMARY KEY (id)<br>) ENGINE=InnoDB;<br><br>-- Workflow (Action: Engineer-Issue(Customer))<br>CREATE TABLE workflow (<br>action_id INT UNSIGNED NOT NULL AUTO_INCREMENT,<br>engineer_id SMALLINT UNSIGNED NOT NULL, <br>issue_id SMALLINT UNSIGNED NOT NULL,<br>PRIMARY KEY (action_id)<br>) ENGINE=InnoDB;<br><br>INSERT INTO engineers (e_name, e_surname, url)<br>VALUES<br>('Miguel', 'Nieto', 'https://www.percona.com/about-us/our-team/miguel-angel-nieto'),<br>('Marcos', 'Albe', 'https://www.percona.com/about-us/our-team/marcos-albe'),<br>('Valerii', 'Kravchuk', 'https://www.percona.com/about-us/our-team/valerii-kravchuk'),<br>('Michael', 'Rikmas', 'https://www.percona.com/about-us/our-team/michael-rikmas');<br><br>INSERT INTO customers (company_name, url)<br>VALUES<br>('OT','http://www.ovaistariq.net/'),<br>('PZ','http://www.peterzaitsev.com/'),<br>('VK','http://mysqlentomologist.blogspot.com/'),<br>('FD','http://www.lefred.be/'),<br>('AS','http://mysqlunlimited.blogspot.com/'),<br>('SS','https://www.flamingspork.com/blog/');<br><br>INSERT INTO issues(customer_id, description)<br>VALUES<br>(1,'Fix replication'),<br>(2,'Help with installation of Percona Cluster'),<br>(3,'Hardware suggestions'),<br>(4,'Error: no space left'),<br>(5,'Help with setup daily backup by Xtrabackup'),<br>(6,'Poke sales about Support agreement renewal'),<br>(4,'Add more accounts for customer'),<br>(2,'Create Hot Fix of Bug 1040735'),<br>(1,'Query optimisation'),<br>(1,'Prepare custom build for Solaris'),<br>(2,'explain about Percona Monitoring plugins'),<br>(6,'Prepare access for customer servers for future work'),<br>(5,'Decribe load balancing for pt-online-schema-change'),<br>(4,'Managing deadlocks'),<br>(1,'Suggestions about buffer pool size');<br><br>INSERT INTO workflow (engineer_id, issue_id)<br>VALUES (1,1),(4,2),(2,3),(1,4),(3,5),(2,6),(3,7),(2,8),(2,9),(1,10),(3,11),(2,12),(2,13),(3,14),(1,15),(1,9),(4,14),(2,9),(1,15),(3,10),(4,2),(2,15),(4,8),(4,4),(3,11),(1,7),(3,7),(1,1),(1,9),(3,4),(4,3),(1,5),(1,7),(1,4),(2,4),(2,5);

-- Engineers CREATE TABLE engineers ( id SMALLINT UNSIGNED NOT NULL AUTO_INCREMENT, e_name VARCHAR(30) NOT NULL, e_surname VARCHAR(30) NOT NULL, url VARCHAR(255) NOT NULL, PRIMARY KEY (id) ) ENGINE=InnoDB; -- Customers CREATE TABLE customers ( id SMALLINT UNSIGNED NOT NULL AUTO_INCREMENT, company_name VARCHAR(30) NOT NULL, url VARCHAR(255) NOT NULL, PRIMARY KEY (id) ) ENGINE=InnoDB; -- Issues (Issue-Customer) CREATE TABLE issues ( id MEDIUMINT UNSIGNED NOT NULL AUTO_INCREMENT, customer_id VARCHAR(30) NOT NULL, description TEXT, PRIMARY KEY (id) ) ENGINE=InnoDB; -- Workflow (Action: Engineer-Issue(Customer)) CREATE TABLE workflow ( action_id INT UNSIGNED NOT NULL AUTO_INCREMENT, engineer_id SMALLINT UNSIGNED NOT NULL, issue_id SMALLINT UNSIGNED NOT NULL, PRIMARY KEY (action_id) ) ENGINE=InnoDB; INSERT INTO engineers (e_name, e_surname, url) VALUES ('Miguel', 'Nieto', 'https://www.percona.com/about-us/our-team/miguel-angel-nieto'), ('Marcos', 'Albe', 'https://www.percona.com/about-us/our-team/marcos-albe'), ('Valerii', 'Kravchuk', 'https://www.percona.com/about-us/our-team/valerii-kravchuk'), ('Michael', 'Rikmas', 'https://www.percona.com/about-us/our-team/michael-rikmas'); INSERT INTO customers (company_name, url) VALUES ('OT','http://www.ovaistariq.net/'), ('PZ','http://www.peterzaitsev.com/'), ('VK','http://mysqlentomologist.blogspot.com/'), ('FD','http://www.lefred.be/'), ('AS','http://mysqlunlimited.blogspot.com/'), ('SS','https://www.flamingspork.com/blog/'); INSERT INTO issues(customer_id, description) VALUES (1,'Fix replication'), (2,'Help with installation of Percona Cluster'), (3,'Hardware suggestions'), (4,'Error: no space left'), (5,'Help with setup daily backup by Xtrabackup'), (6,'Poke sales about Support agreement renewal'), (4,'Add more accounts for customer'), (2,'Create Hot Fix of Bug 1040735'), (1,'Query optimisation'), (1,'Prepare custom build for Solaris'), (2,'explain about Percona Monitoring plugins'), (6,'Prepare access for customer servers for future work'), (5,'Decribe load balancing for pt-online-schema-change'), (4,'Managing deadlocks'), (1,'Suggestions about buffer pool size'); INSERT INTO workflow (engineer_id, issue_id) VALUES (1,1),(4,2),(2,3),(1,4),(3,5),(2,6),(3,7),(2,8),(2,9),(1,10),(3,11),(2,12),(2,13),(3,14),(1,15),(1,9),(4,14),(2,9),(1,15),(3,10),(4,2),(2,15),(4,8),(4,4),(3,11),(1,7),(3,7),(1,1),(1,9),(3,4),(4,3),(1,5),(1,7),(1,4),(2,4),(2,5);

Examples:

List of issues for each engineer (GROUP_CONCAT):

mysql&gt; SELECT<br>    -&gt;  CONCAT (e_name, ' ', e_surname) AS engineer,<br>    -&gt;  GROUP_CONCAT(DISTINCT issue_id, ' (', c.company_name,')' ORDER BY issue_id SEPARATOR ', ' ) AS 'issue (customer)'<br>    -&gt; FROM <br>    -&gt;  workflow w,<br>    -&gt;  engineers e,<br>    -&gt;  customers c,<br>    -&gt;  issues i<br>    -&gt; WHERE<br>    -&gt;  w.engineer_id = e.id<br>    -&gt;  AND w.issue_id = i.id<br>    -&gt;  AND i.customer_id = c.id<br>    -&gt; GROUP BY<br>    -&gt;  e.id <br>    -&gt; ORDER BY  <br>    -&gt;  e_name, e_surname;<br>+------------------+---------------------------------------------------------------------------+<br>| engineer         | issue (customer)                                                          |<br>+------------------+---------------------------------------------------------------------------+<br>| Marcos Albe      | 3 (VK), 4 (FD), 5 (AS), 6 (SS), 8 (PZ), 9 (OT), 12 (SS), 13 (AS), 15 (OT) |<br>| Michael Rikmas   | 2 (PZ), 3 (VK), 4 (FD), 8 (PZ), 14 (FD)                                   |<br>| Miguel Nieto     | 1 (OT), 4 (FD), 5 (AS), 7 (FD), 9 (OT), 10 (OT), 15 (OT)                  |<br>| Valerii Kravchuk | 4 (FD), 5 (AS), 7 (FD), 10 (OT), 11 (PZ), 14 (FD)                         |<br>+------------------+---------------------------------------------------------------------------+<br>4 rows in set (0.00 sec)

mysql> SELECT -> CONCAT (e_name, ' ', e_surname) AS engineer, -> GROUP_CONCAT(DISTINCT issue_id, ' (', c.company_name,')' ORDER BY issue_id SEPARATOR ', ' ) AS 'issue (customer)' -> FROM -> workflow w, -> engineers e, -> customers c, -> issues i -> WHERE -> w.engineer_id = e.id -> AND w.issue_id = i.id -> AND i.customer_id = c.id -> GROUP BY -> e.id -> ORDER BY -> e_name, e_surname; +------------------+---------------------------------------------------------------------------+ | engineer | issue (customer) | +------------------+---------------------------------------------------------------------------+ | Marcos Albe | 3 (VK), 4 (FD), 5 (AS), 6 (SS), 8 (PZ), 9 (OT), 12 (SS), 13 (AS), 15 (OT) | | Michael Rikmas | 2 (PZ), 3 (VK), 4 (FD), 8 (PZ), 14 (FD) | | Miguel Nieto | 1 (OT), 4 (FD), 5 (AS), 7 (FD), 9 (OT), 10 (OT), 15 (OT) | | Valerii Kravchuk | 4 (FD), 5 (AS), 7 (FD), 10 (OT), 11 (PZ), 14 (FD) | +------------------+---------------------------------------------------------------------------+ 4 rows in set (0.00 sec)

List of engineers for each customer (GROUP_CONCAT inside of GROUP_CONCAT):

mysql&gt; SELECT<br>    -&gt;  c.company_name AS company,<br>    -&gt;  GROUP_CONCAT(DISTINCT issue_id, ' (', engineer_list, ')' ORDER BY issue_id SEPARATOR ', ' ) AS issue<br>    -&gt; FROM <br>    -&gt;  workflow w,<br>    -&gt;  engineers e,<br>    -&gt;  customers c,<br>    -&gt;  issues i,<br>    -&gt;  (SELECT<br>    -&gt;    i.id AS i_id,<br>    -&gt;    GROUP_CONCAT(DISTINCT CONCAT(e_name, ' ', e_surname) ORDER BY e_name SEPARATOR ', ') AS engineer_list<br>    -&gt;   FROM <br>    -&gt;    workflow w,<br>    -&gt;    engineers e,<br>    -&gt;    issues i<br>    -&gt;   WHERE<br>    -&gt;    w.engineer_id = e.id<br>    -&gt;    AND w.issue_id = i.id<br>    -&gt;   GROUP BY<br>    -&gt;    i.id) AS e_list<br>    -&gt; WHERE<br>    -&gt;  w.engineer_id = e.id<br>    -&gt;  AND w.issue_id = i.id<br>    -&gt;  AND i.customer_id = c.id<br>    -&gt;  AND w.issue_id = e_list.i_id<br>    -&gt; GROUP BY<br>    -&gt;  c.id <br>    -&gt; ORDER BY  <br>    -&gt;  c.company_name;<br>+---------+--------------------------------------------------------------------------------------------------------------------------------------------+<br>| company | issue (engineer)                                                                                                                           |<br>+---------+--------------------------------------------------------------------------------------------------------------------------------------------+<br>| AS      | 5 (Marcos Albe, Miguel Nieto, Valerii Kravchuk), 13 (Marcos Albe)                                                                          |<br>| FD      | 4 (Marcos Albe, Michael Rikmas, Miguel Nieto, Valerii Kravchuk), 7 (Miguel Nieto, Valerii Kravchuk), 14 (Michael Rikmas, Valerii Kravchuk) |<br>| OT      | 1 (Miguel Nieto), 9 (Marcos Albe, Miguel Nieto), 10 (Miguel Nieto, Valerii Kravchuk), 15 (Marcos Albe, Miguel Nieto)                       |<br>| PZ      | 2 (Michael Rikmas), 8 (Marcos Albe, Michael Rikmas), 11 (Valerii Kravchuk)                                                                 |<br>| SS      | 6 (Marcos Albe), 12 (Marcos Albe)                                                                                                          |<br>| VK      | 3 (Marcos Albe, Michael Rikmas)                                                                                                            |<br>+---------+--------------------------------------------------------------------------------------------------------------------------------------------+<br>6 rows in set (0.00 sec)

mysql> SELECT -> c.company_name AS company, -> GROUP_CONCAT(DISTINCT issue_id, ' (', engineer_list, ')' ORDER BY issue_id SEPARATOR ', ' ) AS issue -> FROM -> workflow w, -> engineers e, -> customers c, -> issues i, -> (SELECT -> i.id AS i_id, -> GROUP_CONCAT(DISTINCT CONCAT(e_name, ' ', e_surname) ORDER BY e_name SEPARATOR ', ') AS engineer_list -> FROM -> workflow w, -> engineers e, -> issues i -> WHERE -> w.engineer_id = e.id -> AND w.issue_id = i.id -> GROUP BY -> i.id) AS e_list -> WHERE -> w.engineer_id = e.id -> AND w.issue_id = i.id -> AND i.customer_id = c.id -> AND w.issue_id = e_list.i_id -> GROUP BY -> c.id -> ORDER BY -> c.company_name; +---------+--------------------------------------------------------------------------------------------------------------------------------------------+ | company | issue (engineer) | +---------+--------------------------------------------------------------------------------------------------------------------------------------------+ | AS | 5 (Marcos Albe, Miguel Nieto, Valerii Kravchuk), 13 (Marcos Albe) | | FD | 4 (Marcos Albe, Michael Rikmas, Miguel Nieto, Valerii Kravchuk), 7 (Miguel Nieto, Valerii Kravchuk), 14 (Michael Rikmas, Valerii Kravchuk) | | OT | 1 (Miguel Nieto), 9 (Marcos Albe, Miguel Nieto), 10 (Miguel Nieto, Valerii Kravchuk), 15 (Marcos Albe, Miguel Nieto) | | PZ | 2 (Michael Rikmas), 8 (Marcos Albe, Michael Rikmas), 11 (Valerii Kravchuk) | | SS | 6 (Marcos Albe), 12 (Marcos Albe) | | VK | 3 (Marcos Albe, Michael Rikmas) | +---------+--------------------------------------------------------------------------------------------------------------------------------------------+ 6 rows in set (0.00 sec)

PHP/HTML? Why not? It’s easy 🙂

Source Code:

“; foreach($rows as $row) { echo “‘.$row[“company”].”.$row[“description”].”.$row[“engineer_list”].’ ‘; } echo “

“.$row[“id”].’

“; $result->close(); $mysqli->close(); ?>

Result:

1	OT	Fix replication	Miguel Nieto
2	PZ	Help with installation of Percona Cluster	Michael Rikmas
3	VK	Hardware suggestions	Marcos Albe, Michael Rikmas
4	FD	Error: no space left	Marcos Albe, Michael Rikmas, Miguel Nieto, Valerii Kravchuk
5	AS	Help with setup daily backup by Xtrabackup	Marcos Albe, Miguel Nieto, Valerii Kravchuk
6	SS	Poke sales about Support agreement renewal	Marcos Albe
7	FD	Add more accounts for customer	Miguel Nieto, Valerii Kravchuk
8	PZ	Create Hot Fix of Bug 1040735	Marcos Albe, Michael Rikmas
9	OT	Query optimisation	Marcos Albe, Miguel Nieto
10	OT	Prepare custom build for Solaris	Miguel Nieto, Valerii Kravchuk
11	PZ	explain about Percona Monitoring plugins	Valerii Kravchuk
12	SS	Prepare access for customer servers for future work	Marcos Albe
13	AS	Decribe load balancing for pt-online-schema-change	Marcos Albe
14	FD	Managing deadlocks	Michael Rikmas, Valerii Kravchuk
15	OT	Suggestions about buffer pool size	Marcos Albe, Miguel Nieto
